Премиальное сетевое оборудование и коммуникационное оборудование Huawei
Huawei из Китая — это также Huawei мира.
Маршрутизатор Huawei NetEngine 8000 X4
Описание
Huawei NetEngine 8000 X4 Router is a highly integrated, intelligent platform designed for the coming era of cloud technology.
| Коммутационная способность | Производительность пересылки | Max. Capacity of a Board | Capacity Density (G/U) | IPU | SFU | Processing Board/Subcard | Power Supply Module | Fan Module | Typical Power Consumption |
| 41.89 Tbit/s | 7248 Mpps | 4 Tbit/s | 1633 | 2, 1+1 | 8, 7+1 | 4 | Max 6, N+1 | 6, 5+1 | 5913 W |
Huawei NetEngine 8000 X4 Router Product Overview
Huawei NetEngine 8000 X4 Router is a full-service intelligent router platform for the cloud era launched by Huawei. The ultra-wide pipeline creates a simple network. The leading SR / SRv6 enables intelligent connection. The new generation of intelligent brain realizes full life cycle automation and leadership. Active operation and maintenance
The 5G and cloud era is already underway. IP networks are fundamental for 5G infrastructure. Ultra-large bandwidths and application-level SLA are required to deliver the massive connectivity services needed for 5G vertical industries. The intelligent and all-service-in-one metro network is set to become an industry trend. The three key characteristics of metro networks in the 5G and cloud era are: simplified networks, intelligent connectivity, and committed high availability.
Huawei NetEngine 8000 X4 Router Product Specifications
| Параметр | NetEngine 8000 X8 | NetEngine 8000 X4 | NetEngine 8000 M14 | NetEngine 8000 M8 | NetEngine 8000 M6 | NetEngine 8000 M1A | NetEngine 8000 F1A |
| Коммутационная способность | 83.78 Tbit/s | 41.89 Tbit/s | 4 Tbit/s | 2.4 Tbit/s | 320 Gbit/s | 352 Gbit/s | 2.4 Tbit/s |
| Производительность пересылки | 14,496 Mpps | 7248 Mpps | 906 Mpps | 453 Mpps | 72 Mpps | 72 Mpps | 453 Mpps |
| Max. Capacity of a Board | 4 Tbit/s | 4 Tbit/s | 200 Gbit/s | 200 Gbit/s | 50 Gbit/s | Fixed box | Fixed box |
| Capacity Density (G/U) | 2025 | 1633 | 400 | 400 | 53 | 176 | 1200 |
| IPU | 2, 1+1 | 2, 1+1 | 2, 1+1 | 2, 1+1 | 2, 1+1 | Fixed box | Fixed box |
| SFU | 8, 7+1 | 8, 7+1 | 2, 1+1 (integrated) | 2, 1+1 (integrated) | 2, 1+1 (integrated) | Fixed box | Fixed box |
| Processing Board/Subcard | 8 | 4 | 14(DC) 10(AC) | 8(DC) 6(AC) | 6(DC) 4(AC) | Fixed box | Fixed box |
| Power Supply Module | Max 10, N+1 | Max 6, N+1 | 2, 1+1 (DC) 4, 2+2 (AC) | 2, 1+1 | 2, 1+1 | 2, 1+1 (DC) | 2, 1+1 |
| Fan Module | 12, 11+1 | 6, 5+1 | 4, 3+1 | 2, 1+1 | 2, 1+1 | 3 (integrated) | 4, 3+1 |
| Размеры (В x Ш x Г) | 702.3 x 442 x 861.4 mm (15.8 U) | 435.6 x 442 x 861.4 mm (9.8 U) | 222 x 442 x 220 mm (5 U) | 132.6 x 442 x 220 mm (3 U) | 88.9 x 442 x 220 mm (2 U) | 44.45 x 442 x 220 mm (1 U) | 43.6 x 442 x 420 mm (1 U) |
| Typical Power Consumption | 11,017 W | 5913 W | 1223 W | 530 W | 475 W | 80 W | 350 W |
| Weight (With Full Configuration) | 296.6 kg | 186.2 kg | 27.4 kg | 16.5 kg | 3.52 kg | 3.4 kg | 7.25 kg |
Huawei NetEngine 8000 X4 Router Product Features
Full-Lifecycle Automation
Full-lifecycle automation is implemented through NCE, a next generation, high availability O&M system. NCE and SRv6 work together to implement 50 ms protection switching, minute-level traffic optimization, second-level fault identification, and minute-level fault locating, significantly improving network availability and enabling enterprise customers to implement proactive and intelligent network O&M.
New platform: industry’s largest capacity with 14.4T/slot, and all-service in one
v provides the industry’s largest capacity with a 14.4T/slot, which is 1.5 times the industry average and highest density – up to 36 x 400GE ports or 72 x 100GE ports. NetEngine 8000 series features a compact design –powerful heat dissipation, efficient power supply and a converged platform with SR, PE, and DC-GW together to simplify the network site and reduce cost.
New protocol stack: Support SRv6 for intelligent connectivity with the first commercial deployment
Huawei NetEngine 8000 X4 Router offer SRv6 capability, which can effectively cope with the massive connections required, provides an improved user experience, and helps operators achieve a smooth evolution from MPLS to SRv6. SRv6 is based on native IPv6 and meets the requirements for massive connections. SRv6 also provides expansion capabilities to implement automatic cross-domain connection and minute-level service provisioning, achieving one-click connection to cloud of service configurations, performing service awareness with tenant/app level SLA assurance.
The NetEngine 8000 X4 is a cornerstone in Huawei’s routing portfolio, delivering unmatched performance and flexibility for modern network demands. Whether deploying 5G infrastructure or expanding enterprise services, this router ensures reliable, intelligent, and scalable connectivity.
