華為ME60-X16
產品概述
The Huawei ME60-X16 is a high-capacity multi-service control gateway designed to serve as the backbone of broadband metropolitan area networks (MANs) and IP/MPLS core networks. As part of Huawei’s ME60 series, it acts as a Broadband Remote Access Server (BRAS), offering a unified platform for user access, service provisioning, and network management.
This router excels in environments requiring seamless integration of multiple services, including high-speed Internet, VoIP, IPTV, and enterprise-grade connectivity. With support for PPPoE, IPoE, and L2TP protocols, the ME60-X16 ensures efficient user authentication and traffic control. Its modular design allows for flexible scaling, making it suitable for both small-scale deployments and large-scale carrier-grade networks.
Built on Huawei’s proven BRAS architecture, the ME60-X16 combines high performance with reliability, delivering low-latency processing and robust security features. It is particularly well-suited for industries such as education, broadcasting, and enterprise services, where consistent and secure connectivity is critical.
Model | 交換容量 | 轉發效能 | Number of Slots | Dimensions (H x W x D) mm | 最大功耗 | Full Configuration Weight | |
ME60-X16 | 12.58太比特/秒 | 5,760 Mpps | 22 slots, including 16 LPUs, 2 SRUs, and 4 SFUs | 1,420 x 442 x 650 (32U) | 4,610W (BSUF-100) | 6,210W (BSUF-240) | 279 kg |
Purchase Recommendation
For enterprises and service providers seeking a scalable, high-performance router for multi-service access, the 華為ME60-X16 stands out as a top choice. Here’s why:
- Future-Proof Design: With 16 slots and support for 100GE interfaces, it adapts to growing bandwidth demands and evolving service requirements.
- Carrier-Grade Reliability: Dual power supplies, redundant components, and advanced thermal management ensure uninterrupted operation in mission-critical environments.
- Unified Service Platform: Seamlessly integrates PPPoE, IPoE, and L2TP protocols to simplify user access and service provisioning.
- Flexible Scalability: Modular architecture allows incremental upgrades, reducing upfront costs while supporting long-term growth.
- Proven Ecosystem: Compatible with Huawei’s iMaster NCE and eSight management tools, ensuring smooth integration with existing network infrastructures.
Compared to other ME60 models like the ME60-X3 or ME60-X8, the ME60-X16 offers superior throughput and interface density, making it ideal for large-scale deployments. For carrier-grade applications, the ME60-X16A provides similar capabilities with enhanced redundancy options.
Huawei ME60-X16 Router Product Specifications
Specifications | ME60-X16A | ME60-X8A | ME60-X16 | ME60-X8 | ME60-X3 |
交換容量 | 50.32 Tbit/s | 25.16 Tbit/s | 12.58太比特/秒 | 7.08太比特/秒 | 1.08太比特/秒 |
轉發效能 | 11,520 Mpps | 5,760 Mpps | 5,760 Mpps | 2,880 Mpps | 360 Mpps |
Number of Slots | 22 slots, including 16 LPUs, 2 SRUs, and 4 SFUs | 12 slots, including 8 LPUs, 2 SRUs, and 2 SFUs | 22 slots, including 16 LPUs, 2 SRUs, and 4 SFUs | 11 slots, including 8 LPUs, 2 SRUs, and 1 SFU | 5 slots, including 3 LPUs and 2 SRUs |
Dimensions | 1,778 x 442 x 650 (40U) | 934 x 442 x 650 (21U) | 1,420 x 442 x 650 (32U) | 620 x 442 x 650 (14U) | 175 x 442 x 650 (DC 4U); |
(H x W x D) mm | 220 x 442 x 650 (AC 5U) | ||||
最大功耗 | 7,220W (BSUF-240) | 4,110W (BSUF-240) | 4,610W (BSUF-100) | 2,340W (BSUF-100) | 920W (BSUF-100) |
9,040W (BSUF-480) | 4,770W (BSUF-480) | 6,210W (BSUF-240) | 3,220W (BSUF-240) | ||
Full Configuration Weight | 356 kg | 190 kg | 279 kg | 136 kg | DC: 42 kg (100G) |
AC: 52 kg (100G) |
Huawei ME60-X16 Router Product Ordering Info
類型 | 描述 |
ME60-X16 basic configuration | ME60-X16 integrated chassis components |
ME60-X16 main processing board B4 | |
200Gbps Switching Network Unit B (SFUI-200-B) | |
100Gbps Switching Network Unit E (SFUI-100-E) | |
ME60-X16 switching network unit B | |
ME60-X8 basic configuration | ME60-X8 integrated chassis components (including four DC power supplies) |
Routing Switch Board A5 | |
Routing Switch Board A7 | |
100Gbps Switching Network Unit D (SFUI-100-D) | |
200Gbps Switching Network Unit C (SFUI-200-C) | |
ME60-X3 basic configuration | Integrated DC chassis assembly (ME60-X3) |
ME60-X3 integrated AC chassis components (including dual AC power) | |
Main processing board D2 (including 2G memory and 2G USB) | |
Main processing board D3 (including 4G memory and 2G USB) | |
DC 48V power supply access module | |
Primary power supply–33degC-55degC-90V-280V-53.5V / 30A- rated input 220V full load output, low load half load output | |
10G series boards | Flexible card broadband business processing board (BSUF-10, 4 subslots) |
Flexible card multi-service processing board (MSUF-10, 4 subslots) | |
2-port OC-12c / STM-4c ATM-SFP Flexible Card (BP10) | |
4-port OC-3c / STM-1c ATM-SFP Flexible Card (BP10) | |
4-port Clear Channel E3 / Channelized T3-SMB Flexible Card (BP10) | |
20G series Boards | Flexible card broadband service processing board (BSUF-21,2 subslots) |
1-port 10GBase LAN / WAN-XFP flexible card (BP20) | |
1-port 10GBase LAN / WAN-XFP flexible card E (BP20-E) | |
12-port 100 / 1000Base-X-SFP flexible card (BP20) | |
10-Port 1000Base-X-SFP Flexible Card E (BP20-E) | |
40G series Boards | Flexible card broadband business processing board (BSUF-40, 2 subslots) |
2-port 10GBase LAN / WAN-XFP flexible card (BP40) | |
2-port 10GBase LAN / WAN-XFP flexible card E (BP40-E) | |
20-port 100 / 1000Base-X-SFP flexible card (BP40) | |
20-Port 1000Base-X-SFP Flexible Card E (BP40-E) | |
50G series Boards | 5-port 10GBase LAN / WAN-SFP + integrated broadband business processing board (BSUI-51) |
5-port 10GBase LAN / WAN-SFP + integrated multi-service processing board (MSUI-51) | |
5-port 10GBase LAN / WAN-SFP + integrated broadband service processing board E (BSUI-51-E) | |
4-port 10GBase LAN / WAN-SFP ++ 12-port 100 / 1000Base-X-SFP integrated broadband service processing board (BSUI-51) | |
2-port 10GBase LAN / WAN-SFP ++ 24-port 100 / 1000Base-X-SFP integrated broadband service processing board (BSUI-51) | |
2-port 10GBase LAN / WAN-SFP ++ 24-port 100 / 1000Base-X-SFP integrated broadband service processing board E (BSUI-51-E) | |
48-port 100 / 1000Base-X-SFP integrated broadband service processing board (BSUI-51) | |
Flexible card broadband service processing board (BSUF-51,2 subslots) | |
Flexible card multi-service processing board (MSUF-51,2 subslots) | |
5-port 10GBase LAN / WAN-SFP + flexible card (BP51, occupying two subslots) | |
5-port 10GBase LAN / WAN-SFP + flexible card E (BP51-E, occupying two subslots) | |
2-port 10GBase LAN / WAN-SFP + flexible card (BP51) | |
2-port 10GBase LAN / WAN-SFP + Flexible Card E (BP51-E) | |
24-port 100 / 1000Base-X-SFP flexible card (BP51) | |
24-Port 1000Base-X-SFP Flexible Card E (BP51-E) | |
100G series Boards | 10-port 10GBase WAN / LAN-SFP + integrated broadband service processing board (BSUI-100) |
10-port 10GBase LAN / WAN-SFP + integrated broadband business processing board (MSUI-100) | |
10-port 10GBase LAN / WAN-SFP + integrated broadband service processing board E (BSUI-100-E) | |
Flexible card broadband business processing board (BSUF-100, 2 subslots) | |
1-port 100GBase-CFP flexible card (BP100) | |
Flexible card multi-service processing board (MSUF-100, 2 subslots) | |
6-port 10GBase LAN / WAN-SFP + flexible card (BP100) | |
5-port 10GBase LAN / WAN-SFP + flexible card (BP100) | |
5-port 10GBase LAN / WAN-SFP + Flexible Card E (BP100-E) | |
24-port 100 / 1000Base-X-SFP flexible card (BP51) | |
24-Port 1000Base-X-SFP Flexible Card E (BP51-E) | |
240G series Boards | Flexible card broadband business processing board (BSUF-240, 2 subslots) |
Flexible card multi-service processing board (MSUF-240, 2 sub-slots) | |
10-port 10GBase LAN / WAN-SFP + flexible card (BP240) | |
10-port 10GBase LAN / WAN-SFP + Flexible Card E (BP240-E) | |
12-port 10GBase LAN / WAN-SFP + flexible card (BP240) | |
1-port 100GBase-CFP flexible card (BP240) | |
Service Processing Board | Universal Service Board (VSUI-20-A) |
Universal Service Board (VSUF-40) | |
General Service Single Board (VSUF-80) | |
Universal Business Single Board Daughter Card (SP80) | |
General Service Board (VSUF-160) | |
Universal Business Single Board Daughter Card (SP160) | |
Software | ME60 basic software (4K users), V600R008 |
MultiserviceEngine60 Rn to R (n + 1) software version fee | |
ME60 DSG Function License | |
ME60 LNS & LTS Function License | |
ME60 cross-machine high reliability function license | |
IP Performance Measurement License (IP FPM) | |
ME60 Ethernet Performance Detection License | |
ME60 concurrent user license (1k users) | |
ME60 IPSec Board Function License VSUI-20-A | |
ME60 2M NAT Session License | |
ME60 VSU Series Board DS-Lite Function License | |
ME60 VSU Series Board NAT64 Function License | |
ME60 VSU Series Single Board PCP Function License | |
ME60 VSU series single board 20G license |
Final Summary
In an era where network complexity and service demands are constantly rising, the 華為ME60-X16路由器 emerges as a trusted partner for enterprises and service providers. Whether you’re managing a broadband MAN, IP/MPLS core network, or multi-play service infrastructure, this router delivers the performance, scalability, and reliability needed to stay ahead.
Its ability to unify user access, support diverse services, and scale with your needs makes it more than just a router — it’s a foundation for innovation. By choosing the ME60-X16, you’re not only investing in cutting-edge technology but also in a solution that grows with your business, ensuring every connection is secure, efficient, and future-ready.
Make the right choice today. Choose Huawei ME60-X16.
